Bitumen 132kv Double Circuit Galvanized Steel Pole , Steel Power Poles
galvanised steel poles
,power line pole
Bitumen 132kv double circuit Galvanized Steel Pole for electrical transmission
Specification
| Product name | Bitumen 132kv double circuit Galvanized Steel Pole for electrical transmission |
| Material | ASTM A572,S355,Q235,Q345,Q360 or equivalent internation standard |
| Design service | available,just offer design parameter |
| Certificate | ISO 9001:2008,etc |
| Destruction test | Available |
| welding method | CO2 welding or submerged arc auto welding |
| OEM | Available |
| Wind pressure | 5-300KM/H |
| Pre-shipment test | Available |
Production process
Raw material test → Cutting →Molding or bending →Welidng (longitudinal )→Dimension verify →Flange welding →Hole drilling →Calibration → Deburr→Galvanization or powder coating ,painting →Recalibration →Thread →Package
Features
1. We can supply the product base on client required drawing ,but also can supply the design for any kinds of lamp poles ,electric poles ,street lighting poles, high mast poles ,garden light poles , outdoor lighting ,outdoor lighting poles ,flag poles ,traffic light poles ,lighting ,road lighting pole.
2. Matercial :hot rolled coil from Q235 to Q460 ,ASTM573 GR65, GR50 ,SS400, SS490,ST52-3
3. Deal: Hot dip galvanized Following ASTM A 123 or any other stardand by client required.
4. Packing: Plastic bulble , Mat &Straw Bale or following client required
5. Length : within 16meters once forming( single section)
6. Thickness: from 1mm to 25mm
7. Shape: polygonal(6-side,8side,12-side,16side) round tapered.
8. 110KV to 220kv
9. Easy install and maintenance.
