10.5m 138kv Hot Dip Galvanized Steel Power Pole for Transmission Line with Wind Speed 160 Km/Hour and Earthquake Resistant Design
10.5m 138kv Hot Dip Galvanized Steel Power Pole for Transmission Line with Wind Speed 160 Km/Hour and Earthquake Resistant Design
Thuộc tính cơ bản
Nơi xuất xứ:
Trung Quốc
Tên thương hiệu:
MilkyWay
Chứng nhận:
ISO9001/BV/
Số mô hình:
Cột thép mạ kẽm
Giao dịch Bất động sản
Số lượng đặt hàng tối thiểu:
1 PC
Giá:
Có thể đàm phán
Điều khoản thanh toán:
T/T, L/C tại tầm nhìn
Khả năng cung cấp:
300 chiếc mỗi ngày
Tóm tắt sản phẩm
10.5m 138kv Electrical Supplies Transmission Line Steel Round Power Pole for Power Distribution Network High-quality steel power pole designed for 138kv transmission lines in power distribution networks, offering superior strength and durability. Product Specifications Specification Details Suit for ...
Thuộc tính tùy chỉnh sản phẩm
Làm nổi bật
Wind Speed 160 Km/Hour Steel Power Pole
,ISO 9001 Certified Transmission Line Pole
,Earthquake Resistant Electric Power Pole
Tên sản phẩm:
Cột thép mạ kẽm
Ứng dụng:
đường truyền
Thiết kế:
Tùy chỉnh
Xử lý bề mặt:
Mạ kẽm nhúng nóng
tiêu chuẩn hàn:
AWS D1.1
độ dày mạ điện:
Trung bình 86um
Vật liệu:
Q345
Mô tả sản phẩm
Thông số kỹ thuật chi tiết và đặc điểm
10.5m 138kv Electrical Supplies Transmission Line Steel Round Power Pole for Power Distribution Network
High-quality steel power pole designed for 138kv transmission lines in power distribution networks, offering superior strength and durability.
Product Specifications
| Specification | Details |
|---|---|
| Suit for | 10.5m 138kv Electrical Supplies Transmission Line Steel Round Power Pole |
| Shape | Conoid, Multi-pyramidal, Columniform, polygonal or conical |
| Material | Q345B/A572 (minimum yield strength≥345n/mm²), Q235B/A36 (minimum yield strength≥235n/mm²), Hot rolled coil from Q460, ASTM573 GR65, GR50, SS400, SS490 to ST52- |
| Tolerance of dimension | ±2% |
| Power | 10KV ~550KV |
| Safety Factor | 8 for conducting wire, 8 for grounding wire |
| Design Load | 300~1000Kg applied to 50cm from the top pole |
| Marks | Name plate through rivet or glue, engrave, emboss as per customer requirement |
| Surface treatment | Hot dip galvanized following ASTM A123, color polyester powder or any other standard by client required |
| Joint of Poles | Insert mode, inner flange mode, face to face joint mode |
| Design of pole | Against earthquake of 8 grade |
| Wind Speed | 160 Km/Hour (30 m/s) |
| Minimum yield strength | 355 MPa |
| Minimum ultimate tensile strength | 490 MPa |
| Max ultimate tensile strength | 620 MPa |
| Standard | ISO 9001 |
| Length of per section | Within 14m once forming without slip joint |
| Welding | Passed flaw testing, internal and external double welding, AWS (American Welding Society) D1.1 standard |
| Thickness | 1mm to 30mm |
| Production Process | Raw material test → Cutting → Molding/bending → Welding (longitudinal) → Dimension verify → Flange welding → Hole drilling → Calibration → Deburr → Galvanization/powder coating/painting → Recalibration → Thread → Packages |
| Packages | Normally covered by mat or straw bale at top and bottom, can follow client requirements. Loading capacity per 40HC/OT calculated based on client specifications |
10 Advantages of Steel Utility Poles
- Easy to Handle
- Light Weight
- Long Life
- Cost Effective
- Low Maintenance
- Sustainable
- Durable
- Safe
- Aesthetics
- Engineered for Strength
Production Process
Raw material test → Cutting → Bending → Welding (longitudinal) → Dimension verify → Flange welding → Hole drilling → Sample assemble → Surface clean → Galvanization or powder coating/painting → Recalibration → Packages
Company Background
JiangSu Milky Way Steel Poles Co., Ltd. was established in 1988, located in Yixing City, Jiangsu Province, Wan Shi Town, covering an area of 35,000 square meters with annual output value reaching 200 million. With 20 years experience in design and production, our main products include power poles, communication towers, street lighting poles, and steel brackets. The company features strong technical force, advanced production equipment, and perfect quality management system, with product quality reaching international advanced level.
