11KV 38KV Hot Dip Galvanized Electric Power Pole with ISO 9001 Certification and IP 65 Rating for High Wind Speed 160km/h

một 40 HQ
MOQ
Có thể đàm phán
giá bán
11KV 38KV Hot Dip Galvanized Electric Power Pole with ISO 9001 Certification and IP 65 Rating for High Wind Speed 160km/h
Đặc trưng Bộ sưu tập Mô tả sản phẩm Yêu cầu báo giá
Đặc trưng
Thông số kỹ thuật
Kiểu: cực thẳng, cực kéo, cực rẽ
Xử lý bề mặt: Nóng nhúng mạ kẽm
Độ dày: 1mm đến 30mm
Lắp ráp quang học của thiết bị chiếu sáng: IP 65
Khối lượng kích thước: +-2%
Tốc độ gió: 160km/h, 30m/s
Làm nổi bật:

ISO 9001 Certified Electric Power Pole

,

IP 65 Rated Utility Power Pole

,

High Wind Speed Steel Power Pole

Thông tin cơ bản
Nguồn gốc: Trung Quốc
Hàng hiệu: Milky Way
Chứng nhận: ISO, BV,
Số mô hình: Các cực điện phân phối tiện ích thép mạ kẽm đa mặt cho dự án điện
Thanh toán
chi tiết đóng gói: Theo yêu cầu của khách hàng
Thời gian giao hàng: thường là 2 tuần sau khi xác nhận
Điều khoản thanh toán: T/t
Khả năng cung cấp: 300 cái cực mỗi ngày
Mô tả sản phẩm
11KV 38KV Hot Dip Galvanized Electric Power Pole

High tensile strength octagonal utility poles with flaw testing and ISO 9001 certification.

Product Specifications
Minimum yield strength 355 mpa
Minimum ultimate tensile strength 490 mpa
Max ultimate tensile strength 620 mpa
Standard ISO 9001
Length per section Within 14m once forming without slip joint
Welding Passed flaw testing. Internal and external double welding meets AWS (American Welding Society) D 1.1 standard
11KV 38KV Hot Dip Galvanized Electric Power Pole with ISO 9001 Certification and IP 65 Rating for High Wind Speed 160km/h 0
Production Process

Our advanced production line includes bending calibration machines, hydraulic plate shears, slitting machines, 208T hydraulic straighteners, and other specialized equipment to ensure high-quality steel poles.

The fabrication process includes:

  • Plate cutting and bending
  • Forming and automatic welding
  • Drill holes and pre-galvanizing quality checks
  • Hot dip galvanizing and powder coating
  • Final quality inspection according to client requirements
Key Features
  • Custom designs available for various pole types (lighting, electric, traffic, flag poles)
  • Materials: Q235-Q460 hot rolled coil, ASTM573 GR65/GR50, SS400/SS490, ST52-3
  • Hot dip galvanized per ASTM A123 or client specifications
  • Single section lengths up to 16 meters
  • Thickness range: 1mm to 22mm
  • Multiple shapes: polygonal (6-16 sides) or round tapered
  • Easy installation and maintenance
11KV 38KV Hot Dip Galvanized Electric Power Pole with ISO 9001 Certification and IP 65 Rating for High Wind Speed 160km/h 1
Our Services
  • 24-hour response to inquiries
  • English-speaking technical support
  • Custom designs (UEM&UBM welcome)
  • Engineer-developed solutions
  • Distributor discounts and sales protection
  • 11+ years manufacturing experience
  • Sample availability for large orders
  • Quality materials and production processes
