220KV 10kv-138kv Rated Electrical Power Pole with AWS D.1.1 Welding Standard for Transmission Line

10
MOQ
$99
giá bán
220KV 10kv-138kv Rated Electrical Power Pole with AWS D.1.1 Welding Standard for Transmission Line
Đặc trưng Bộ sưu tập Mô tả sản phẩm Yêu cầu báo giá
Đặc trưng
Thông số kỹ thuật
Xếp hạng hiện tại: 220kV
Điện áp định mức: 10kv-138kv
Chiều cao gắn kết: 14m
Hình dạng: Hình nón tròn; Hình nón hình bát giác; Hình vuông thẳng; Bước ống; Đa giác
tiêu chuẩn hàn: AWS D.1.1
Độ dày mạ kẽm: Trung bình 80-100
Lớp phủ bột: Bức tranh bột polyester tinh khiết
Sức đề kháng gió: 3-500km/h
Độ dày vật liệu: 1 mm đến 30 mm
Tấm gốc: Hình vuông hoặc tròn với các lỗ có rãnh
Chiều dài gắn trên mặt đất: theo yêu cầu của khách hàng
dấu ngoặc: Đơn hoặc gấp đôi theo yêu cầu của khách hàng
Vật liệu: Thép truyền điện 14m 500 dan
Loại hàn: Hàn kép bên trong và bên ngoài
Quá trình sản xuất: CNC Laser Cutting, Hàn hồ quang tự động
Làm nổi bật:

220KV Rated Electrical Power Pole

,

10kv-138kv Rated Transmission Line Pole

,

AWS D.1.1 Welding Standard Steel Power Pole

Thông tin cơ bản
Nguồn gốc: Jiangsu, Trung Quốc
Hàng hiệu: Milky Way
Số mô hình: Điện PLE
Thanh toán
Mô tả sản phẩm
Electric Pole Specifications
General Specifications
Feature Description
Material 14M 500 Dan Electricity Transmission Steel Utility Pole For Power Distribution Line Project
Mounting Height 14m
Shape of Pole Round conical; Octagonal conical; Straight square; Tubular stepped; Polygonal
Brackets Single or double brackets as per customer requirements
Welding Conforms with international welding standard of CWB
Base Plate Square or round with slotted holes for anchor bolts
Ground Mounting Buried length as per customer requirements
Galvanizing Hot dip galvanization (80-100µm average thickness)
Powder Coating Pure polyester powder painting (color optional)
Wind Resistance 3-500km/h
Welding Standard AWS (American Welding Society) D 1.1
Thickness 1 mm to 30 mm
220KV 10kv-138kv Rated Electrical Power Pole with AWS D.1.1 Welding Standard for Transmission Line 0
Production Process
Raw Material
Steel plates are purchased with mill certificates. Quality department performs elongation tests and chemical composition analysis to ensure materials meet required standards before production.
Cutting
Materials are cut to required dimensions using CNC laser cutting technology, ensuring high-quality surface finish on all edges.
220KV 10kv-138kv Rated Electrical Power Pole with AWS D.1.1 Welding Standard for Transmission Line 1 220KV 10kv-138kv Rated Electrical Power Pole with AWS D.1.1 Welding Standard for Transmission Line 2
Molding
Cut steel plates are formed into required shapes (circular, polygonal, etc.) using specialized bending machines.
Welding
Plates are welded longitudinally using A.C. inverter controlled welding machines with seam-tracking arc-guide mechanism for precision alignment.
220KV 10kv-138kv Rated Electrical Power Pole with AWS D.1.1 Welding Standard for Transmission Line 3 220KV 10kv-138kv Rated Electrical Power Pole with AWS D.1.1 Welding Standard for Transmission Line 4
Galvanization
All poles are hot-dip galvanized internally and externally according to IS2629-1985 and BS729-1971 standards.
Certifications
220KV 10kv-138kv Rated Electrical Power Pole with AWS D.1.1 Welding Standard for Transmission Line 5
Company Profile
220KV 10kv-138kv Rated Electrical Power Pole with AWS D.1.1 Welding Standard for Transmission Line 6
Jiangsu Milky Way Steel Poles Co.,Ltd.
Established in 1991 and located in Wuxi, near Shanghai port. Our products are used in power transmission, signal transmission, and lighting applications worldwide.
With over 20 years of experience, we've exported to more than 70 countries including USA, Australia, Russia, Germany, Spain, Philippines, and Malaysia. We are BV, ISO, and SGS certified.
Packing & Delivery
220KV 10kv-138kv Rated Electrical Power Pole with AWS D.1.1 Welding Standard for Transmission Line 7
Packing Specification Details
Size 40HQ
Weight 26T
Packaging Details Poles are packed with sea/road-worthy wooden materials. Loading capacity per container varies based on client specifications.
Frequently Asked Questions
How can I get a price for needed pole?
1. Provide exact dimensions (height, thickness, material, diameters) for a quote.
2. Send drawings for precise pricing.
Do you accept small orders?
Yes, we welcome small wholesalers and are happy to grow with our customers.
Can you produce custom designed samples?
Yes, we welcome opportunities to help bring custom designs to reality.
How to apply to be your agent?
Send your proposal and company profile to delia@yin-he.com.
Do you offer door-to-door delivery service?
Yes, we provide complete door-to-door service including customs clearance, with discounted shipping rates.
