Galvanized Steel Street Light Pole 6m 9m 12m 20ft 25ft 30ft Octagonal Round Type for 10KV-550KV with 300-1000 Kg Design Load

100
MOQ
$99
giá bán
Galvanized Steel Street Light Pole 6m 9m 12m 20ft 25ft 30ft Octagonal Round Type for 10KV-550KV with 300-1000 Kg Design Load
Đặc trưng Bộ sưu tập Mô tả sản phẩm Yêu cầu báo giá
Đặc trưng
Thông số kỹ thuật
Vật liệu: Q235 Q345 Q420
Xử lý bề mặt: Nóng nhúng mạ kẽm
tiêu chuẩn mạ điện: ASTM A123
tiêu chuẩn hàn: AWS D.1.1
năng suất căng thẳng: tối thiểu 450mpa
Phạm vi năng lượng: 10KV ~550KV
Thiết kế tải: 300 ~ 1000 kg
Độ dày: 2,5mm
Kháng động đất: lớp 8
loại khớp: Chèn, bên trong, mặt đối mặt
Hình dạng: Hình nón, đa kim tự tháp, cột, đa giác, hình nón
Kích thước đóng gói: 40hq
Trọng lượng đóng gói: 26T
Phương pháp cắt: CNC cắt laser
Phương pháp hàn: Mối hàn dọc
Làm nổi bật:

6m 9m 12m 20ft 25ft 30ft Steel Street Light Pole

,

10KV-550KV Electrical Power Pole

,

300-1000 Kg Design Load Galvanized Steel Pole

Thông tin cơ bản
Nguồn gốc: Jiangsu, Trung Quốc
Hàng hiệu: Milky Way
Số mô hình: Cột điện
Thanh toán
Mô tả sản phẩm
Galvanized Octagonal Steel Street Light Poles

High-quality galvanized steel poles available in 6m, 9m, 12m, 20ft, 25ft, and 30ft lengths with octagonal or round configurations.

Product Specifications
Type 450Mpa Min Yield Stress Electrical Power Pole, Cross Arm Galvanised Steel Poles
Application Electricity distribution
Shape Conoid, Multi-pyramidal, Columniform, Polygonal or Conical
Material Q235, Q345, Q420
Power 10KV ~550KV
Design Load 300~1000Kg applied to 50cm from the top pole
Surface Treatment Hot dip galvanized (ASTM A 123), color polyester powder, or client-specified standard
Joint Types Insert mode, inner flange mode, face to face joint mode
Seismic Rating Designed against earthquake of 8 grade
Standard ISO 9001
Welding Internal and external double welding (AWS D1.1 standard), passed flaw testing
Thickness 2.5mm
Galvanized Steel Street Light Pole 6m 9m 12m 20ft 25ft 30ft Octagonal Round Type for 10KV-550KV with 300-1000 Kg Design Load 0
Production Process
Galvanized Steel Street Light Pole 6m 9m 12m 20ft 25ft 30ft Octagonal Round Type for 10KV-550KV with 300-1000 Kg Design Load 1
Raw Material

All raw materials include mill certificates and undergo elongation tests and chemical composition analysis before production.

Cutting Process

CNC laser cutting precisely shapes materials according to specifications, leaving high-quality surface finishes.

Galvanized Steel Street Light Pole 6m 9m 12m 20ft 25ft 30ft Octagonal Round Type for 10KV-550KV with 300-1000 Kg Design Load 2 Galvanized Steel Street Light Pole 6m 9m 12m 20ft 25ft 30ft Octagonal Round Type for 10KV-550KV with 300-1000 Kg Design Load 3
Molding

Steel plates are formed into specified shapes (circular, polygonal, etc.) using precision bending machines.

Welding

Longitudinal welds are performed using AC inverter control with seam-tracking arc-guide mechanisms for perfect alignment.

Galvanized Steel Street Light Pole 6m 9m 12m 20ft 25ft 30ft Octagonal Round Type for 10KV-550KV with 300-1000 Kg Design Load 4 Galvanized Steel Street Light Pole 6m 9m 12m 20ft 25ft 30ft Octagonal Round Type for 10KV-550KV with 300-1000 Kg Design Load 5
Galvanization

All poles receive complete hot-dip galvanization (IS2629-1985, BS729-1971 standards) for superior corrosion protection.

Certifications
Galvanized Steel Street Light Pole 6m 9m 12m 20ft 25ft 30ft Octagonal Round Type for 10KV-550KV with 300-1000 Kg Design Load 6 Galvanized Steel Street Light Pole 6m 9m 12m 20ft 25ft 30ft Octagonal Round Type for 10KV-550KV with 300-1000 Kg Design Load 7 Galvanized Steel Street Light Pole 6m 9m 12m 20ft 25ft 30ft Octagonal Round Type for 10KV-550KV with 300-1000 Kg Design Load 8 Galvanized Steel Street Light Pole 6m 9m 12m 20ft 25ft 30ft Octagonal Round Type for 10KV-550KV with 300-1000 Kg Design Load 9
Company Profile
Galvanized Steel Street Light Pole 6m 9m 12m 20ft 25ft 30ft Octagonal Round Type for 10KV-550KV with 300-1000 Kg Design Load 10

Jiangsu Milky Way Steel Poles Co., Ltd. - Established in 1991, located in Wuxi, China. Our products are used worldwide in power transmission, signal transmission, and street/road lighting applications.

With over 20 years of manufacturing experience, we've exported to more than 70 countries including USA, Australia, Russia, Germany, Spain, and throughout Asia.

Packing & Delivery
Galvanized Steel Street Light Pole 6m 9m 12m 20ft 25ft 30ft Octagonal Round Type for 10KV-550KV with 300-1000 Kg Design Load 11
Packing Size 40HQ
Weight 26T

Poles are packed with sea/road-worthy wooden materials. Loading capacity per container varies based on specifications.

Our Services
  • 24-hour inquiry response
  • Customized designs (UEM&UBM available)
  • Professional engineering solutions
  • Distributor discounts and sales protection
  • 20+ years manufacturing expertise
  • Sample availability for large orders
  • Superior materials and quality control
Galvanized Steel Street Light Pole 6m 9m 12m 20ft 25ft 30ft Octagonal Round Type for 10KV-550KV with 300-1000 Kg Design Load 12
Frequently Asked Questions
How can I get a price for needed poles?

Provide exact dimensions (height, thickness, material, diameters) or send drawings for accurate pricing.

Do you accept small orders?

Yes, we work with wholesalers of all sizes and support business growth.

Can you produce custom designed samples?

We welcome custom designs and will work to make your specifications a reality.

How to become an agent?

Submit your business profile and market plan to delia@yin-he.com.

Do you offer door-to-door service?

Yes, we provide complete shipping solutions including customs clearance.
