9m 10m 11m Octagonal Steel Power Pole with Cross Arm Accessories for 33kv Transmission Line

50
MOQ
$99
giá bán
9m 10m 11m Octagonal Steel Power Pole with Cross Arm Accessories for 33kv Transmission Line
Đặc trưng Bộ sưu tập Mô tả sản phẩm Yêu cầu báo giá
Đặc trưng
Thông số kỹ thuật
Điện áp định mức: 33KV
Vật liệu: GR.65
Xử lý bề mặt: Nóng hông mạ kẽm
tiêu chuẩn mạ điện: ASTMA123
tiêu chuẩn hàn: AWS D.1.1
Hình dạng: 8 bên
Thiết kế kháng: Động đất 8 lớp
Độ dày: 4-5mm
Chiều cao: 9m, 10m, 11m
Loại cực: Hình bát giác
Kích thước container: 40hq
Trọng lượng thùng chứa: 26T
Quá trình sản xuất: CNC cắt laser
Loại hàn: Mối hàn dọc
Lớp thép: Gr65
Làm nổi bật:

9m Steel Power Pole

,

10m Electrical Power Pole

,

11m Transmission Line Pole

Thông tin cơ bản
Nguồn gốc: Jiangsu, Trung Quốc
Hàng hiệu: Milky Way
Số mô hình: Điện PLE
Thanh toán
Mô tả sản phẩm
33kV 9m 10m 11m Octagonal Steel Power Pole With Cross Arm Accessories
Product Overview

JiangSu Milky Way Steel Poles Co., Ltd. specializes in manufacturing high-quality steel poles for power transmission and distribution. Established in 1988 with over 20 years of experience, our facility covers 35,000 square meters with an annual output value of 200 million. Our products meet international quality standards.

9m 10m 11m Octagonal Steel Power Pole with Cross Arm Accessories for 33kv Transmission Line 0
Type 75FT 4-5mm Thickness Philippines NGCP Standard Galvanized Steel Pole
Suit For Electricity distribution
Material Gr65
Shape 8-side (Octagonal)
Standard ISO 9001
Surface Treatment Hot dip galvanized Following ASTM A 123, color polyester powder or client specifications
Design Earthquake resistant (8 grade)
Production Process
9m 10m 11m Octagonal Steel Power Pole with Cross Arm Accessories for 33kv Transmission Line 1
Raw Material

All raw materials (steel plates) include mill certificates. Our quality department performs elongation tests and chemical composition analysis to ensure materials meet required standards before production begins.

Cutting

Materials are precision-cut using CNC laser cutting technology, following programmed patterns to achieve exact dimensions with high-quality surface finishes.

9m 10m 11m Octagonal Steel Power Pole with Cross Arm Accessories for 33kv Transmission Line 2 9m 10m 11m Octagonal Steel Power Pole with Cross Arm Accessories for 33kv Transmission Line 3
Molding

Cut steel plates are formed into specified shapes (circular, octagonal, or custom designs) using precision bending machines.

Welding

Longitudinal welding is performed using AC inverter-controlled equipment with seam-tracking systems for perfect alignment and high efficiency.

9m 10m 11m Octagonal Steel Power Pole with Cross Arm Accessories for 33kv Transmission Line 4 9m 10m 11m Octagonal Steel Power Pole with Cross Arm Accessories for 33kv Transmission Line 5
Galvanization

All poles receive complete hot-dip galvanization (internal and external) meeting IS2629-1985 and BS729-1971 standards or client specifications.

Certifications
9m 10m 11m Octagonal Steel Power Pole with Cross Arm Accessories for 33kv Transmission Line 6 9m 10m 11m Octagonal Steel Power Pole with Cross Arm Accessories for 33kv Transmission Line 7 9m 10m 11m Octagonal Steel Power Pole with Cross Arm Accessories for 33kv Transmission Line 8 9m 10m 11m Octagonal Steel Power Pole with Cross Arm Accessories for 33kv Transmission Line 9
Company Profile
9m 10m 11m Octagonal Steel Power Pole with Cross Arm Accessories for 33kv Transmission Line 10

Established in 1991, Jiangsu Milky Way Steel Poles Co., Ltd. is located in Wuxi, near Shanghai Port. Our products serve power transmission, signal transmission, and street lighting applications worldwide.

With over 20 years of export experience to 70+ countries including USA, Australia, Russia, Germany, Spain, Philippines, and Malaysia, we are BV, ISO, and SGS certified manufacturers committed to quality.

Packing & Delivery
9m 10m 11m Octagonal Steel Power Pole with Cross Arm Accessories for 33kv Transmission Line 11
Packing Sea/road-worthy wooden packing
Size 40HQ container
Weight 26T

Packaging can be customized to client requirements. Loading capacity per container depends on actual pole specifications.

Why Choose Us?
  • 24-hour inquiry response
  • English-speaking support staff
  • Custom design services (UEM/UBM welcome)
  • Professional engineering solutions
  • Distributor discounts and protection
  • 20+ years manufacturing experience
  • Sample availability for large orders
  • Quality materials and advanced production
9m 10m 11m Octagonal Steel Power Pole with Cross Arm Accessories for 33kv Transmission Line 12
