HDg 9m mạ kẽm cực đường phố sơn tĩnh điện với cánh tay chéo

1 pcs
MOQ
Có thể đàm phán
giá bán
HDg 9m mạ kẽm cực đường phố sơn tĩnh điện với cánh tay chéo
Đặc trưng Bộ sưu tập Mô tả sản phẩm Yêu cầu báo giá
Đặc trưng
Thông số kỹ thuật
Tên sản phẩm: Cột đèn đường
Nguồn cấp: Năng lượng mặt trời / AC
Tiêu chuẩn hàn: AWS D 1.1
Vật chất: Q345
Cả đời: 50 năm
Sức mạnh của Dimenstion: + - 2%
Hoàn thành: HDG
Làm nổi bật:

Cột đèn đường mạ kẽm hdg

,

cột đèn mạ kẽm 9m

,

cột đèn đường mạ kẽm 9m

Thông tin cơ bản
Place of Origin: China
Hàng hiệu: MilkyWay
Chứng nhận: ISO9001/BV/
Model Number: Street Light Poles
Thanh toán
Packaging Details: As customer request
Delivery Time: 20 working days after received your payment
Payment Terms: T/T, L/C at sight
Supply Ability: 300pcs per day
Mô tả sản phẩm

 HDG 9m Outdoor Street Light Poles Powder Coating with Cross Arms





 Specifications:

Height

From 3 meter to 15 meter

Suit for

Airport, seaport, roadway, etc

Shape

Round conical; Octagonal tapered; Straight square; Tubular stepped;

Shafts are made of steel sheet that folded into required shape and

welded longitudinally by automaticarc welding machine

Material

 Q235B or Q345 by , same grade EN44 .SS400

Tolerance of the dimension

According to client’s requirement.

Surface treatment

Hot dip galvanized Following ASTM A 123, color polyester

powder or any other standard by client required.

Joint of Poles

Slip joint, flanged connected

Base plate mounted

Base plate is square or round in shape with slotted holes for

anchor bolt and dimension as per customers requirement.

Wind Resistance

Aganist wind pressure of 160Km/h

Certificates

ISO 9001:2008

Length of per section

Within 14 meter once forming

Welding Standard

AWS (American Welding Society ) D 1.1

Thickness

1 mm to 36mm

Production Process

Raw material test → Cutting →bending →Welding (longitudinal )

→Dimension verify →Flange welding →Hole drilling →sample assemble

→ surface clean→ Galvanization or powder coating ,painting →Recalibration

→Packages

Packages

Packing with plastic paper or according to client’s request.





 Production Process

 Raw material test → Cutting →bending →Welding (longitudinal )→Dimension verify →Flange welding  →Hole drilling →sample assemble → surface clean→ Galvanization or powder coating ,painting  →Recalibration →Packages

 HDg 9m mạ kẽm cực đường phố sơn tĩnh điện với cánh tay chéo 0







 Package:

 Our poles as normal cover by Mat or straw bale at the top and bottom ,
 anyway also can following by client required , each 40HC or OT can
 loading how many pcs will calculation base on the client actually
 specification and data.

 HDg 9m mạ kẽm cực đường phố sơn tĩnh điện với cánh tay chéo 1
