Steel Telecom Cellular Antenna Mono Pole Tower For Communication , ISO 9001

Trung Quốc Steel Telecom Cellular Antenna Mono Pole Tower For Communication , ISO 9001 nhà cung cấp
Steel Telecom Cellular Antenna Mono Pole Tower For Communication , ISO 9001 nhà cung cấp Steel Telecom Cellular Antenna Mono Pole Tower For Communication , ISO 9001 nhà cung cấp Steel Telecom Cellular Antenna Mono Pole Tower For Communication , ISO 9001 nhà cung cấp Steel Telecom Cellular Antenna Mono Pole Tower For Communication , ISO 9001 nhà cung cấp

Hình ảnh lớn :  Steel Telecom Cellular Antenna Mono Pole Tower For Communication , ISO 9001

Thông tin chi tiết sản phẩm:

Place of Origin: Jiangsu,China
Hàng hiệu: Milky Way
Chứng nhận: ISO9001/BV/SGS
Model Number: Mono Pole Tower

Thanh toán:

Minimum Order Quantity: 1 pcs
Giá bán: Negotiation
Packaging Details: As customer request
Delivery Time: 20 working days after received your payment
Payment Terms: T/T or L/C at sight
Supply Ability: 300pcs per day
Contact Now
Chi tiết sản phẩm
Galvanization standard: ASTM A 123 Product Name: Steel High Quality Telecom Cellular Antenna towers Mono Pole Tower For Communication
Application: Communication distribution  Design: Customized
Surface treatment: hot dip galvanization Dimension torlance: +- 2%
Welding standard: AWS D 1.1 Standard: ISO

Steel High Quality Telecom Cellular Antenna towers Mono Pole Tower For Communication





Specifications:



Suit for

Communication distribution

Shape

Conoid ,Multi-pyramidal,Columniform,polygonal or conical

Material

Usually Q345B/A572,minimum yield strength>=345n/mm2
Q235B/A36,minimum yield strength>=235n/mm2
As well as Hot rolled coil from Q460 ,ASTM573 GR65, GR50 ,

SS400, SS490, to ST52-

Torlance of the dimension

+- 2%

Power

10  KV ~550 KV

Safety Factor

Safety factor for conducting wine : 8
Safety factor for grounding wine : 8

Design Load in Kg

300~ 1000 Kg applied to 50cm from the to pole

Marks

Name plate through rivert or glue ,engrave ,emboss as per customer

 requirement

Surface treatment

Hot dip galvanized Following ASTM A 123,
color polyester power or any other standard by client required

Joint of Poles

Insert mode,innerflange mode,face to face joint mode

Design of pole

Against earthquake of 8 grade

Wind Speed

160 Km/Hour .  30 m /s

Minimum yield strength

355 mpa

Minimum ultimate tensile

 strength

490 mpa

Max ultimate tensile

strength

620 mpa

Standard

ISO 9001

Length of per section

Within 14m once forming without slip joint

Welding

We has past flaw testing.Internal and external double welding makes
the welding beautiful in shape
Welding Standard :AWS ( American Welding Society ) D 1.1

Thickness

1 mm to 30 mm

Production Process

Row material test → Cutting →Molding or bending →
Welding (longitudinal )→Dimension verify →Flange welding
→Hole drilling →Calibration → Deburr→Galvanization or
powder coating ,painting →Recalibration →Thread →Packages

Packages

Our poles as normal cover by Mat or straw bale at the top and bottom ,
anyway also can following by client required , each 40HC or OT can
loading how many pcs will calculation base on the client actually
specification and data



Steel Telecom Cellular Antenna Mono Pole Tower For Communication , ISO 9001





Description:



The communication tower is used for the communication distribution.



Steel Telecom Cellular Antenna Mono Pole Tower For Communication , ISO 9001



The material we use is from Baosteel.According to the different strength request,we can use the Q235,Q345 and GR65.The strength of GR 65 is best and Q235 is lowest.




Production Flow:


The production process:Row material test → Cutting →Molding or bending →Welding (longitudinal )→Dimension verify →Flange welding→Hole drilling →Calibration → Deburr→Galvanization or powder coating ,painting →Recalibration →Thread →Packages





Company Introduction:



Steel Telecom Cellular Antenna Mono Pole Tower For Communication , ISO 9001



Estbilsed in 1991,Jiangsu Milky Way Steel Poles is located in Wuxi,East of China ,near one of the largest sea port of China ,Shanghai,Port .
Our Products have been widely used in the power transmsion ,signal transmission and ligting for street ,road ,square ,palaestra.and so on

We have plenty of export experience . Since our first overseas order from Pakstan in 1991 of 132 KV transmission poels ,our products have been deliveried to more than 70 contries and areas ,including America,Australia ,Russia ,Genmery ,Span,Philippines ,Malaysia and so on
