Solid Copper Ground Rod Electrical Grounding Rod Corrosion Resistance

Trung Quốc Solid Copper Ground Rod Electrical Grounding Rod Corrosion Resistance nhà cung cấp
Solid Copper Ground Rod Electrical Grounding Rod Corrosion Resistance nhà cung cấp Solid Copper Ground Rod Electrical Grounding Rod Corrosion Resistance nhà cung cấp Solid Copper Ground Rod Electrical Grounding Rod Corrosion Resistance nhà cung cấp Solid Copper Ground Rod Electrical Grounding Rod Corrosion Resistance nhà cung cấp

Hình ảnh lớn :  Solid Copper Ground Rod Electrical Grounding Rod Corrosion Resistance

Thông tin chi tiết sản phẩm:

Place of Origin: China
Hàng hiệu: Milky Way
Chứng nhận: CE,UL467,ISO9001:2008
Model Number: ground rod

Thanh toán:

Minimum Order Quantity: 10 pieces
Giá bán: US $0.1-5 per piece
Packaging Details: Nylon Or Wooden cases Or container
Delivery Time: 5-15 days
Payment Terms: L/C, T/T, D/A, D/P, Western Union, MoneyGram
Supply Ability: 500 tons per month
Contact Now
Chi tiết sản phẩm
Product name: Ground rod Material: Copper clad steel
Type: Threaded or flat or pointed Usage: Underground
Copper layer thickness: 0.254mm, 0.33mm, 0.5mm, 1.0mm Application: Lightning protection
Elongation: 8%-15% Straightness: <1mm/m

Solid copper clad steel ground rod with ground rod accessories

Specifications:

Tell us your specific requirements (customized diameter, copper thickness, length) or provide complete drawings

 and specifications can get a quotation.

Ground Rod Size List
Small Size
Model Diameter Copper Thickness Length N.W. Packing
inch mm Mil mm Feet mm kgs/pc pc/bundles
YH-8   8 10 0.254 3 900 0.45 20
YH-8   8 10 0.254 4 1200 0.45 20
YH-8   8 10 0.254 5 1500 0.45 20
YH-9   9 10 0.254 3 900 0.57 20
YH-9   9 10 0.254 4 1200 0.57 20
YH-9   9 10 0.254 5 1500 0.57 20
YH-10   10 10 0.254 3 900 0.7 20
YH-10   10 10 0.254 4 1200 0.7 20
YH-10   10 10 0.254 5 1500 0.7 20
YH-11   11 10 0.254 3 900 0.85 20
YH-11   11 10 0.254 4 1200 0.85 20
YH-11   11 10 0.254 5 1500 0.85 20
YH-12   12 10 0.254 3 900 1.01 20
YH-12   12 10 0.254 4 1200 1.01 20
YH-12   12 10 0.254 5 1500 1.01 20
YH-13   13 10 0.254 3 900 1.18 20
YH-13   13 10 0.254 4 1200 1.18 20
YH-13   13 10 0.254 5 1500 1.18 20
YH-13   13 10 0.254 6 1800 1.18 20
YH-14 5/8 14..2 10 0.254 4 1200 1.54 20
YH-14 5/8 14.2 10 0.254 6 1800 2.3 10
YH-14 5/8 14.2 10 0.254 8 2400 3.07 10
YH-14 5/8 14.2 10 0.254 10 3000 3.84 10
YH-14 5/8 14.2 10 0.254 20 6000 7.68 5
YH-16   14.2 10 0.254 4 1200 1.95 10
YH-16   16 10 0.254 6 1800 2.93 10
YH-16   16 10 0.254 8 2400 3.9 10
YH-16   16 10 0.254 10 3000 4.88 10
YH-16   16 10 0.254 20 6000 9.75 5
YH-17 3/4 17.2 10 0.254 4 1200 2.25 10
YH-17 3/4 17.2 10 0.254 6 1800 3.38 10
YH-17 3/4 17.2 10 0.254 8 2400 4.51 10
YH-17 3/4 17.2 10 0.254 10 3000 5.64 7
YH-17 3/4 17.2 10 0.254 20 6000 11.27 5
YH-18   18 10 0.254 4 1200 2.47 10
YH-18   18 10 0.254 10 3000 6.17 7
YH-18   18 10 0.254 20 6000 12.34 5
YH-20   20 10 0.254 6 1800 4.57 10
YH-20   20 10 0.254 8 2400 6.1 10
YH-20   20 10 0.254 10 3000 7.62 7
YH-20   20 10 0.254 20 6000 15.24 5
YH-20   20 10 0.254 8 2400 6.1 10
YH-22   22 10 0.254 10 3000 9.22 7
YH-22   22 10 0.254 6 1800 5.53 10
YH-25   25 10 0.254 8 2400 9.53 10
YH-25   25 10 0.254 10 3000 11.91 7
YH-25   25 10 0.254 20 6000 23.81 5
Also supply copper layer thickness 0.33mm,0.5mm and 1.0mm
Also supply any length shorter than 6000mm



Description:

Copper bonded ground rod is mainly used in the grounding device. Due to its good conductivity, corrosion resistance,

, low prices, etc.,

Copper bonded ground rod can be widely used, and have been recognized by the United States Institute of Electrical and Electronics Engineering (IEEE) standard, BS standard and International Electrotechnical Commission (IEC) standards.

In China, have been recognized in China Sinopec, China National Petroleum, the national electricity company, and gradually be widely used.

Solid Copper Ground Rod Electrical Grounding Rod Corrosion Resistance



Packaging & Shipping:

Strong packing is available and free of charge ,which is suitable for loading, storage in most popular

condition .Custom packing will be charged reasonably to favor customer’s requirement .

Solid Copper Ground Rod Electrical Grounding Rod Corrosion Resistance



Company introduction:

Estbilsed in 1991,Jiangsu Milky Way Steel Poles is located in Wuxi,East of China ,near one of the largest sea port of China ,Shanghai,Port .Our Products have been widely used in the power transmsion ,signal transmission and ligting for street ,road ,square ,palaestra.and so on.

We have plenty of export experience . Since our first overseas order from Pakstan in 1991 of 132 KV transmission poels ,our products have been deliveried to more than 70 contries and areas ,including America,Australia ,Russia ,Genmery ,Span,Philippines ,Malaysia and so on.

Solid Copper Ground Rod Electrical Grounding Rod Corrosion Resistance
